530 Cov Kabmob Pob Txhuam DC Tsav
Qhov hnyav: Txog 57g
Daim Ntawv Thov: Fais gramophone, Dub tshuab zaj duab xis
530 Cov Kabmob Pob Txhuam DC Tsav
Khoom Piav Qhia
Yam khoom: | EG-530SD-3F DC txhuam txhuam lub cev muaj zog nrog kho ceev |
Loj ： | +32.5mm |
Ncej ntev: | 16mm |
Voltage: | DC 12.0V |
Nyhav ： | Txog 57g |
Daim ntawv thov: | Hluav taws xob gramophone, Dub zaj duab xis tshuab 、 |
Cov duab ntxaws ntxaws
Khoom& cov lus qhia tshwj xeeb
1.STANDARD OPERATION CONDITION
TSIS TAU: | Yam khoom: | SPECIFICATIONS: |
1-1 | Thov | Fais fais fab xov tooj |
1-2 | Thauj khoom | 5-15g.cm |
1-3 | Cov movies Voltage | 12.0 V DC |
1-4 | Khuv Xim Load g.cm | 8g.cm |
1-5 | Khwv Koob Ceev rpm / min | Tsawg Ceev Midle Ceev Kev kub ceev 1130±2% 1620±2% 2100±2% |
1-6 | Kev Taw Qhia Ua Teb | CW: Pom los ntawm cov zis txuas thaum kawg ： CW |
1-7 | Kev ua haujlwm voltage | 8.4to 16.0V DC |
2.CONSTRUCTION
2-1 | Nyhav | Nplai | Kwv yees.57.5g |
2-2 | Ncej Deflection | Dial gauge 4mm los ntawm lub cev muaj zog mounting suface | 0.01mm lossis tsawg dua 0.01 hli 以下 |
2-3 | Eed-ua si | Diial ntsuas cua | 0.02 ~ 0.30 hli 0.02 ~ 0.30 hli |
TSIS TAU: | Yam khoom: | Kuaj Rau Cov Mob: | Specification: |
3-1 | Rated Load | 8g.cm | |
3-2 | Tsis Muaj Tus Sau Tam Sim No | Ntawm kev ntsuas voltage, tsis muaj load | 20mA lossis tsawg dua 20mA |
3-3 | Rated Load Tam Sim No | Thaum ntsuas Rated voltage, ntaus nqi ntsuas | Tsawg tus ceev ≤60mA nruab nrab dle spee ≤105mA |
3-4 | Tsis Muaj Load Staring V | Ntawm Rated Load | 6v lossis tsawg dua ≤6v |
3-5 | Pib Torque | Ntawm 8.4VDC Thiab Tsawg Tsawg | 40g.cm |
3-6 | Thauj Khoom Sib Nrauj | Ntawm kev ntsuas voltage, rated lo, tsis ceev Ntawm 6.0g.com rau 10g.com | 18-42rpm / min |
3-7 | Neeg Tuaj Tshuab Tsis Zoo | Ntawm 12v, tsis muaj thauj khoom, tsis tshua muaj kev ceev 10CM Cov suab nrov tom qab 55dB lossis tsawg dua 12V | 28dB lossis tsawg dua ≤28dB (A) |
3-8 | Kev Co | Nyob rau ntawm 12v, tsis muaj thauj khoom qhov qeeb ceev Tom Qab Kev Tsoo -40dB lossis tsawg dua | Ntawm 1 lub hauv paus Frepuency, -20db lossis tsawg dua -10dB |
Khoom& tso saib
Packing& Tus me nyuam
POB:
Txheem export thawv ntim khoom.
TXHUA LUB SIJ HAWM:
3-20 hnub tom qab paub tseeb txog kev txiav txim, kev qhia meej txog hnub xa khoom yuav tsum txiav txim siab raws li
lub caij ua ntau lawm thiab kev txiav txim kom muaj nuj nqis.
XAIV:
Yog tias cov ntaub ntawv tshwj xeeb kev lis kev cai tau thov, thov hu rau peb ua ntej kom paub meej.
Cov FAQ
Q: 1.Qhov twg lub cev muaj zog koj tuaj yeem muab tau?
A: Txog rau tam sim no, Peb feem ntau muab micro lub cev muaj zog thiab cov koob ntawm dc deceleration lub cev muaj zog, suav nrog ncaj ncaj deceleration lub cev muaj zog, planetary deceleration tsav, lub cev muaj zog deceleration lub cev muaj zog.Thaum tam sim no, peb lub tuam txhab tsom rua kev tsim ntau yam ntawm cov motors nrog voltage ntawm 1VDC thiab 30VDC thiab lub cev muaj zog txoj kab uas hla ntawm 8 thiab 51 hli.
Q: 2. Koj puas tuaj yeem xa kuv daim ntawv qhia nqi?
A: Rau txhua yam ntawm peb lub zog, lawv tau kho kom haum raws li qhov sib txawv raws li lub neej, suab nrov, voltage, thiab cov nqaj thiab lwm yam. Tus nqi kuj sib txawv raws li qhov ntau xyoo. Yog li nws' s yeej nyuaj rau peb los muab cov npe teev nqi. Yog tias koj tuaj yeem qhia koj cov ncauj lus kom ntxaws thiab cov khoom lag luam txhua xyoo, peb' dhau los saib qhov kev pabcuam peb tuaj yeem muab tau.
Q: 3. Dab tsi' s lub sij hawm txhuas rau kev txiav txim ib txwm?
A: Rau cov xaj, lub sijhawm txhuas lub sijhawm yog 3-25 hnub thiab lub sijhawm no tuaj yeem luv dua lossis ntev dua raws li cov qauv sib txawv, sijhawm thiab ntau.
Q: 4. Nws puas tau rau koj kom txhim kho lub zog tshiab yog tias peb tuaj yeem muab cov nqi tsim tawm?
A:Yog lawm. Thov ua siab zoo qhia cov ncauj lus kom ntxaws ntxaws xws li kev ua tau zoo, qhov loj me, cov lus qhia txhua xyoo, cov nqi phiaj.
Q: 5.Hauv koj xa tuaj rau kuv kuaj dawb?
Yog lawm, peb kuj tuaj yeem xa koj cov nqi coj mus kuaj rov qab thaum koj tso qhov kev txiav txim.
Cim npe nrov: 530 cov kabmob npas kabmob dc lub cev muaj zog, Tuam Tshoj, tuam ntxhab, lub Hoobkas, lag luam, customized, lag luam wholesale, tej, hauv Tshuag
