CHIHAI: Koj tus kws tshaj lij Mini DC Tsav Chaw Tsim Tshuaj!

Cov khoom dav

Shenzhen Chihai Tsav Co., Ltd., nrhiav tau nyob rau hauv 2002, yog ib tugkev tsim khoom ntawm micro dc motors thiab dc txo lub cev muaj zog. Peb lub lag luam pib nrog micro lub cev muaj zog, tom qab ntawd tsim ntau lub zog ntawm DC deceleration motor.

Pab neeg tshaj lij

Peb cov neeg koom tes muaj kev paub ntau xyoo thiab yog cov kws tshaj lij hauv lawv cov haujlwm. Peb muaj ntau tshaj 210 tus neeg ua haujlwm txawj thiab 26 tus kws tshaj lij engineers.

24H Online Service

Cov kev xav tau ntawm peb cov neeg siv khoom ib txwm yog peb qhov tseem ceeb tshaj plaws. Peb ua tib zoo mloog lawv cov kev txhawj xeeb thiab ua haujlwm sib koom tes los nrhiav kev daws teeb meem.

Tus nqi sib tw

Peb muab cov nqi sib tw ntawm txhua yam ntawm peb cov khoom, thiab peb ua haujlwm nrog peb cov neeg siv khoom los tsim cov peev nyiaj uas ua tau raws li lawv cov kev xav tau.

45ZY-2480 Permanent Magnet DC Brushed Tsav
Khoom Piav Qhia: Cov Khoom Siv Plhaub Nyiam: Lub tsev yog ua los ntawm seamless steel raj los ntawm kev txau thiab stamping, muab lub zog siab, kev ua haujlwm ruaj khov, thiab kev ua haujlwm ruaj...
Permanent Magnet DC Coreless Tsav Cwj Pwm Ncej
Cov lus piav qhia: Coreless khob deceleration: Kev sib kis tau zoo, tsis tshua muaj suab nrov thiab siab torque muaj peev xwm. Pob bearing siv: Tsis tshua muaj kev sib txhuam tsis tshua muaj suab...
GM3865-520 Permanent Magnet Dc Geared Tsav DC24V
Khoom Piav Qhia: Txhua yam -hlau iav: Kev txais yuav tag nrho - cov khoom siv hlau iav moret hnav- tiv taus nws lub neej kev pab cuam Ntshiab tooj liab hlau winding: Lub rotor feem txais cov...
CHU-1650 DC Coreless Brushless Tsav
Cov lus piav qhia: Muaj zog Neodymium Iron Boron (NdFeB) Magnets: coreless lub cev muaj zog nrog NdFeB hlau nplaum kom ruaj khov thiab ua haujlwm yooj yim. Precision Machining: Lub cev muaj zog...
GW12T-N30VA DC Worm Iav Tsav
Khoom Piav Qhia: Hlau phaj qauv: lub iav ncej ntawm lub reducer nthuav tawm txhim kho kev ruaj ntseg, txuas ntxiv mus ntev, thiab kev ua haujlwm zoo dua rau siab torque loads Ntshiab tooj liab...
GM29-N30 DC Variable Ceev Tsav
Cov lus piav qhia: Qhov thib ob deceleration siv lub bevel iav kis qauv los hloov cov kev taw qhia tso zis, nce qhov txo qhov piv, nce lub zog, txo qhov tso zis ceev, thiab hloov tag nrho cov zis...
Lub cev muaj zog DC Coreless Iav Tsav 6V 12V
Khoom Piav Qhia: Txhua yam - hlau iav: Kev txais yuav tag nrho - cov khoom siv hlau iav ntau dua- tiv taus ntev nws lub neej kev pab cuam D ncej: yooj yim dua installation, tsis yooj yim rau plam...
DC Coreless Iav Tsav M4 Xov Lub Ncej
Cov Khoom Muag: Precision Tub Rog Zoo Siab precision machined iav: Kev txais siab ntawm - precision machined iav ntau hnav- resistant prolongs nws cov kev pab cuam lub neej M4 Xov ncej: Threaded...
Nrog nraub qaum-mounted ncej dc iav reducer lub cev muaj zog
Cov Khoom Muag Khoom: Txhua Tus-Hlau Zog Khoom: Cov Khoom Siv Hluav Taws Xob Cov Khoom Siv Zoo Nkauj, thiab Lub Cev Muaj Zog Lub Neej Zoo Nkauj
DC cua iav lub cev muaj zog hlau iav 3V 6V 12v
Cov Khoom Muag Khoom: Tus Qauv Hlau Hlau Qauv: Lub iav Ncej ntawm Reducer Hlau Wrops, Tooj Liab Zog, Loj Hluav Taws Xob Zoo, Loj...
DC Thib Ob Pais Loj Loj Tsav Gm 29- n30
Cov Khoom Muag Khoom: Qhov Kev Txiav Txim Siab Thib Ob: Txo cov qauv tso zis ntau dua, thiab hloov cov qauv txo cov zis tshaj tawm, thiab cov teeb meem txo qis aws adopts...
380 Kev Kub Ceev Loog 11V 53000RPM
Cov Khoom Muag Khoom: Ib qho ntawm txhua sab, kev coj ua hluav taws xob zoo nkauj ua kom zoo nkauj

Tsev 12 3 4 5 6 7 Rau sab kawg

Mini DC Tsav yog dab tsi?

Mini DC Tsav, tseem hu ua me me DC lub cev muaj zog, yog lub tshuab hluav taws xob me me uas siv tam sim no ncaj qha (DC) los tsim lub zog siv tshuab. Cov motors no yog compact thiab nrhiav kev siv nyob rau hauv ntau yam khoom siv thiab tshuab.

Qhov zoo ntawm peb Mini DC Tsav

Compact Size

DC motors yog qhov zoo tagnrho rau kev siv nrog qhov chaw txwv vim lawv qhov loj me.

Kev ua tau zoo

Kev xa ncaj qha tam sim no thiab kev tsim qauv zoo ua rau lawv lub zog hloov pauv tau zoo.

Tswj ceev

Kev tswj ceev ceev yog ua tiav los ntawm kev tswj hluav taws xob, ua rau lawv yoog raws ntau yam dej num.

Pib nrawm thiab nres

Cov motors no nthuav tawm lub sijhawm teb sai, ua rau lawv haum rau cov ntawv thov uas xav tau kev hloov pauv sai.

Kev ntseeg tau

Nrog tsawg qhov txav mus los thiab kev tsim kho yooj yim, DC motors me me yuav muaj lub neej ntev dua thiab txo cov kev xav tau ntawm kev saib xyuas.

Tsim Cov Ntsiab Cai ntawm Miniature DC Motors

Ntawm qhov tseem ceeb ntawm txhua lub DC lub cev muaj zog yog ib qho ntawm cov qauv tsim tseem ceeb uas ua rau lawv cov kev ua tau zoo, qhov tseeb, thiab kev ntseeg tau:

Armature thiab Commutator

Lub armature, ib feem tseem ceeb, tsev cov winding coils uas cuam tshuam nrog cov magnetic teb. Cov commutator thiab txhuam hniav pab txhawb qhov ntws ntawm tam sim no, kom ntseeg tau tias kev sib hloov tsis tu ncua.

480 Medium Speed High Torque Shaft Motor

Cov hlau nplaum ruaj khov

Cov hlau nplaum no tsim cov hlau nplaum zoo li qub nyob rau hauv uas lub armature rotates, tsim cov lus tsa suab thaum cov hlau nplaum sib cuam tshuam.

Txhuam thiab Txhuam Txhuam Hniav

Txhuam tuav hluav taws xob tiv tauj nrog lub rotating commutator, ua rau kev hloov hluav taws xob mus rau armature.

Enclosures thiab Bearings

Cov vaj tsev nyob tiv thaiv lub cev muaj zog cov khoom siv sab hauv, thaum cov kabmob zoo ua kom muaj kev sib hloov thiab txo kev sib txhuam.

Hom Mini DC Tsav

DC motors tau muab faib ua ob pawg nyob ntawm seb lawv puas siv cov txhuam hniav thiab cov commutators: Brushed DC motors thiab Brushless DC motors

Brushed Dc Tsav

Brushed DC motors ua haujlwm los ntawm kev sib txuas ncaj qha mus rau qhov chaw ntawm DC fais fab tuag. Lawv tuaj yeem muab faib ua ob hom hauv qab no nyob ntawm seb lawv puas siv cov hlau nplaum ruaj khov lossis electro-magnets.

1) Cov hlau nplaum tas mus li txhuam DC lub cev muaj zog

Qhov no yog hom hluav taws xob feem ntau siv thoob ntiaj teb thiab suav nrog cov motors siv nyob rau hauv cov qauv thiab nyob rau hauv lub auxiliary motors ntawm tsheb. Lawv tau muab faib ntxiv rau hauv slotted, slotless, thiab coreless motors nyob ntawm qhov kev teeb tsa ntawm lub armature.

2) Electromagnet txhuam DC lub cev muaj zog

Cov hom motors no siv electromagnets los tsim magnetic flux. Lawv tau muab faib ntxiv rau hauv kev faib-winding, series-qhov txhab, thiab cais-zoo siab motors nyob ntawm seb qhov hluav taws xob sib txuas ntawm lub teb winding thiab armature winding yog configured. Qhov kev teeb tsa no yog siv rau cov motors nrog nruab nrab mus rau siab tso zis.

Brushless Dc Tsav

Brushless DC motors yuav tsum muaj lub voj voog tsav thiab ua haujlwm los ntawm kev muab cov khoom tsim nyog tam sim no los ntawm cov khoom siv hluav taws xob zoo li qub raws li qhov pom kev taw qhia ntawm cov hlau nplaum ntawm lub rotor. Vim hais tias lawv cov windings tseem zoo li qub, brushless DC motors tsis tas yuav txhuam thiab cov khoom sib txuas. Lawv muab faib ua hom hauv qab no raws li cov hlau nplaum ruaj khov txuas mus rau lub rotor li cas.

1) Nto tas li hlau nplaum (SPM)

Cov hlau nplaum ruaj khov txuas mus rau sab nraud ntawm lub rotor.

2) Sab hauv cov hlau nplaum ruaj khov (IPM)

Cov hlau nplaum ruaj khov yog embedded rau sab hauv ntawm lub rotor.

Kev siv ntawm Mini DC Tsav

Hauv tsev, DC motors me me yog siv rau hauv cov cuab yeej, cov khoom ua si thiab ntau yam khoom siv hauv tsev. Hauv khw muag khoom, cov kev siv ntawm DC motors muaj xws li conveyors thiab turntables, thaum nyob rau hauv ib qho kev lag luam chaw, loj DC lub cev muaj zog siv kuj muaj xws li braking thiab reversing daim ntaub ntawv. Nov yog qee qhov tshwj xeeb siv rau DC motors:

Dc Motors rau cov kiv cua

Txawm hais tias cov kiv cua ib txwm siv AC motors, muaj ntau tus DC motor qab nthab kiv cua ntaus lub khw. Cov kiv cua no tau txais txiaj ntsig zoo vim tias lawv tau nyiaj ntau dua li lawv qhov sib npaug AC, ua tsaug rau txoj hauv kev uas lawv ua haujlwm.

DC motors siv cov khoom sib nqus los ua cov hluav taws xob ua hluav taws xob rau hauv lub tshuab hluav taws xob, thiab los ntawm kev siv lub tshuab tsis txhuam, DC lub cav qab nthab kiv cua tuaj yeem ua los ntawm cov qauv hauv tsev AC hluav taws xob. Qhov tsuas yog downside rau DC lub cev muaj zog kiv cua yog nws cov nqi, tab sis lub zog txuag tau yooj yim offset qhov no.

Dc Motors rau Pumps

Hydraulic twj tso kua mis yog ib qho tseem ceeb ntawm kev lag luam cuab yeej, uas yog siv nyob rau hauv yuav luag tag nrho cov industries xws li kev tsim kho, mining, manufacturing, thiab hlau. DC motors yog siv los ua lub zog rau cov twj no vim lawv qhov kev tswj tau yooj yim sib txawv thiab cov lus teb zoo heev thaum tsiv.

Zoo li cov kiv cua qab nthab, DC lub cev muaj zog twj tso kua mis kuj tau txais txiaj ntsig los ntawm kev txhim kho cov nqi qis qis DC motors, uas yooj yim dua rau kev tswj hwm ntawm qhov kev lag luam loj.

Dc Motors rau cov khoom ua si

DC motors rau cov khoom ua si yog ib qho kev xaiv nrov rau cov tuam txhab thiab cov neeg nyiam nyiam, nrog cov 'cov khoom ua si motors' feem ntau siv rau cov menyuam yaus cov khoom ua si xws li cov chaw taws teeb tswj tsheb thiab cov qauv tsheb ciav hlau. Me DC motors ua haujlwm zoo nyob rau hauv qhov chaw no, vim lawv yooj yim siv thiab tsis tshua muaj rugged.

Qhov ntau yam ntawm voltages rau DC motors txhais tau hais tias lawv tuaj yeem siv rau cov khoom ua si uas xav tau kev sib txawv ntawm qhov sib txawv thiab hom kev txav mus los, thiab cov uas xav tau DC lub cev muaj zog nrog cov maub los.

Dc Motors rau Fais Tsheb

Thaum muaj ntau yam sib txawv ntawm lub cev muaj zog siv nyob rau hauv lub tsheb hluav taws xob, DC motors rau lub tsheb fais fab tau siv dav vim lawv lub zog ua haujlwm thiab ua haujlwm ntev.

Ntxiv nrog rau cov kws tshaj lij, ntau tus neeg nyiam nyiam thiab cov neeg tsim khoom siv tsheb nyiam DC motors loj rau lawv cov pib torque siab dua, tshwj xeeb tshaj yog cov kab mob kis tau tus mob, thiab lawv qhov sib txawv ntawm qhov sib txawv nrog cov khoom siv hluav taws xob.

Dc Motors rau Robots

'Robot' yog ib lo lus dav dav, tab sis rau ntau tus neeg nyiam ua haujlwm thiab cov kws tshaj lij, cov neeg hlau yog txhua yam khoom siv hluav taws xob tsim los ua kom tiav ib txoj haujlwm tshwj xeeb. DC motors rau cov neeg hlau yog siv los ua 'ua haujlwm' ib yam dab tsi, xws li lem, caj npab, lossis lub koob yees duab, lub cev muaj zog tshwj xeeb yog vim li cas.

DC motors yog tshwj xeeb tshaj yog yooj yim, raws li lawv muaj siab torque thiab efficiency, ua rau lawv zoo tagnrho rau robotics.

Dc Motors rau Bikes

Cov tsheb kauj vab hluav taws xob tau nrov vim lawv tsis xav tau daim ntawv tso cai yog tias qhov kev pabcuam siab tshaj plaws yog qis dua 20 mais ib teev. Txhawm rau kom ntseeg tau tias lub zog thiab lub zog xav tau, brushless DC motors feem ntau yog siv rau cov tsheb kauj vab hluav taws xob.

Cov tsheb kauj vab hluav taws xob siv lub cev muaj zog DC ua rau hauv lub hub ntawm lub nraub qaum lossis lub log pem hauv ntej, lossis ntsia rau hauv nruab nrab ntawm lub tsheb kauj vab thiab txuas nrog lub pedal sprocket.

Yuav Ua Li Cas Tshawb Xyuas Mini DC Tsav?

Disconnect lub cev muaj zog los ntawm lub hwj chim qhov chaw thiab npaj cov hlau xaus rau Diagnostics

Siv lub hau ntswj kom tshem tawm cov ntsia hlau los ntawm cov xov hlau sib txuas uas khiav ntawm lub cev muaj zog thiab roj teeb. Thaum tshem tawm, tshem tawm cov xov hlau kom lub cev tsis muaj zog.

Yog tias tsim nyog, nthuav tawm qhov kawg ntawm cov xov hlau kom koj tuaj yeem siv lawv los ua kom tiav qhov ntsuas ntsuas.

Detach lub cev muaj zog los ntawm Nws Lub Tshuab Tsev

Tshem tawm DC lub cev muaj zog los ntawm nws lub tshuab vaj tsev kom lub rotor tuaj yeem txav tau yooj yim thaum kuaj. Nyob ntawm seb hom lub cev muaj zog, koj yuav muaj metric lossis SAE bolts, yog li xyuas kom koj muaj cov cuab yeej zoo rau txoj haujlwm.

Npaj lub Volt-Ohm Meter rau Kev Ntsuas

Teem lub volt-ohm meter rau nws qhov chaw ohms. Txuas tus liab volt-ohm meter coj mus rau hauv qhov chaw ohms, thiab cov hlau lead dub rau hauv av taw tes. Muab cov hlua khi hlua khi ua rau txhua lub cev muaj zog nkag hauv cov xov hlau. Kov ob qho tib si ua ke thiab xyuas kom lub volt-ohm meter nyeem xoom ohms.

Khiav qhov Test

Xyuas lub DC Tsav rau qhov tsis xws luag. Kov cov xov hlau tawm ntawm lub cev muaj zog nrog cov volt-ohm meter coj. Dub mus rau dub thiab liab mus rau liab. Tam sim no, nyeem qhov screen thiab txiav txim siab cov txiaj ntsig:

1) 10 mus rau 100 ohms: Qhov no yog qhov tsis tshua muaj kev tiv thaiv ntau thiab qhia tias tsis muaj dab tsi cuam tshuam nrog lub cev muaj zog.
2) Infinite ohms: Qhov no txhais tau tias muaj qhov qhib Circuit Court thiab yuav tsum tau kuaj ntxiv.

Tig lub Motors Qhov Kawg Ncej thiab sau cov ntawv nyeem tshiab

Maj mam tig lub motor ncej. Yog hais tias lub 'meter' nyeem ntawv hloov thaum lub ncej nyob rau hauv lub zog, lub cev muaj zog yog zoo, tab sis muaj ib tug teeb meem ntawm lub Circuit Court. Yog hais tias lub 'meter' nyeem ntawv tseem qhia tau tias qhib Circuit Court, muaj teeb meem nrog lub cev muaj zog. Feem ntau, koj yuav pom nws yog ib qho ntawm peb qhov teeb meem:

1) luv luv hauv av
2) Tsis zoo conductive bushings
3) Ib tug ua tsis tau tejyam commutator

Test rau luv luv hauv av

Nrhiav ib qho hlau ntawm tus ncej lub cev muaj zog thiab muab cov hlua khi dub rau nws. Yog hais tias lub 'meter' qhia tau hais tias qhib Circuit Court, muaj luv luv hauv av.

Tshem tawm thiab tshuaj xyuas cov Bushings

Nrhiav lub cev muaj zog bushings nyob rau hauv lub hnab yas kawg ntawm sab nraud ntawm lub driveshaft. Siv lub hau ntswj kom tshem tawm cov bushings thiab tom qab ntawd tshuaj xyuas lawv.

Tshawb nrhiav cov kab nrib pleb lossis tawg thoob plaws ntawm qhov chaw ntawm bushings. Yuav tsum muaj qhov nkhaus du qhov twg cov bushings zaum tawm tsam tus commutator. Yog tias koj pom tsis muaj qhov tsis xws luag, qhov teeb meem feem ntau yog commutator.

Tshem tawm thiab tshuaj xyuas lub Commutator

Tshem ob lub hau ntswj uas khiav qhov ntev ntawm lub cev muaj zog thiab tshem tawm lub hau tom qab kawg. Tshawb xyuas cov phaj uas ua rau lub commutator sib dhos.

Koj yuav tsum pom qhov qhib ntawm txhua lub phaj thiab tsis muaj cov xov hlau tawg lossis cov kua roj vanish hlawv. Yog tias koj pom lwm yam, lub commutator tau ua tsis tiav, thiab koj yuav tsum tau hloov cov khoom puas.

Khoom Description

Qhov sib txawv ntawm AC thiab DC motors yog qhov tseem ceeb heev tsis yog los ntawm qhov kev ntsuam xyuas pom, tab sis kuj rau ntau yam haujlwm thiab kev ua qauv qhia. Los ntawm kev paub txog qhov sib txawv ntawm AC thiab DC lub cev muaj zog, xaiv qhov tsim nyog rau ib qho kev ua qauv qhia tau yooj yim. Rau engineering aspirants kuj, lub ncauj lus no tuav qhov tseem ceeb heev.

Sl. Tsis muaj.	Differentiating Khoom	AC Tsav	DC Tsav
1	Txhais	AC lub cev muaj zog tuaj yeem txhais tau tias yog lub tshuab hluav taws xob uas tau tsav los ntawm kev hloov tam sim no (AC).	Lub DC lub cev muaj zog kuj yog lub tshuab hluav taws xob hloov hluav taws xob uas hloov hluav taws xob ncaj qha (DC zog) rau hauv lub zog siv tshuab.
2	Hom	AC motors yog feem ntau ntawm ob hom - synchronous AC motors thiab induction motors.	DC motors kuj tseem yog ob hom - DC motors nrog txhuam thiab DC motors tsis muaj txhuam.
3	Cov tswv yim tam sim no	AC motors tsuas yog khiav thaum ib qho kev hloov tam sim no muab raws li cov khoom siv.	DC motors tsuas yog khiav thaum muab DC muab. Nyob rau hauv cov ntaub ntawv ntawm DC series lub cev muaj zog, lub cev muaj zog yuav khiav nrog AC mov. Tab sis, rau shunt motors, lub cev muaj zog yeej tsis khiav ntawm AC mov.
4	Commutators thiab Txhuam	Cov Commutators thiab txhuam tsis muaj nyob hauv AC motors.	Cov Commutators thiab cov txhuam hniav muaj nyob hauv DC motors.
5	Input Supply Phase	AC motors tuaj yeem khiav ntawm ob theem ib zaug thiab peb-theem khoom siv.	DC motors tuaj yeem khiav ntawm ib theem khoom.
6	Pib ntawm Motor	Peb-theem AC lub cev muaj zog yog pib nws tus kheej, tab sis ib-theem AC lub cev muaj zog yuav tsum muaj lub tshuab pib.	DC motors yeej ib txwm pib nws tus kheej hauv qhov xwm txheej.
7	Armature yam ntxwv	Nyob rau hauv AC motors, lub armature nyob ruaj ruaj thaum lub magnetic teb tig.	Hauv DC motors, armature rotates thaum lub magnetic teb nyob ruaj ruaj.
8	Input Terminals	Nyob rau hauv AC motors, peb input terminals (RYB) yog tam sim no.	Nyob rau hauv DC motors, muaj ob lub input terminals (zoo thiab tsis zoo) tam sim no.
9	Tswj ceev	Qhov ceev ntawm AC lub cev muaj zog tuaj yeem hloov tau los ntawm qhov sib txawv ntawm qhov zaus.	Nyob rau hauv cov ntaub ntawv ntawm DC motors, ceev yuav tswj tau los ntawm kev hloov lub armature winding tam sim no.
10	Load Hloov	AC motors qhia cov lus teb qeeb rau kev hloov pauv hauv kev thauj khoom.	DC motors qhia cov lus teb ceev rau qhov kev hloov pauv hauv kev thauj khoom.
11	Lub neej expectancy	Txij li thaum AC motors tsis muaj txhuam thiab commutators, lawv muaj zog heev thiab muaj lub neej expectancy.	Cov txhuam hniav thiab cov commutators hauv DC motors txwv qhov ceev thiab txo lub neej expectancy ntawm lub cev muaj zog.
12	Kev ua tau zoo	Vim qhov poob tam sim no thiab lub cev muaj zog, qhov ua tau zoo ntawm AC lub cev muaj zog tsawg dua.	Qhov ua tau zoo ntawm DC lub cev muaj zog yog siab vim tias tsis muaj plam thiab induction tam sim no poob.
13	Kev tu	AC motors xav tau kev saib xyuas tsawg dua vim cov txhuam hniav thiab cov commutators tsis tuaj.	DC motors xav tau kev saib xyuas ntau dhau vim muaj cov txhuam hniav thiab cov commutators.
14	Daim ntawv thov	AC motors yuav tsum muaj qhov xav tau kev kub ceev thiab hloov pauv torque.	DC motors yuav tsum tau nyob qhov twg yog qhov yuav tsum tau hloov pauv ceev thiab siab torque.
15	Kev siv tswv yim	Lawv tsuas yog siv hauv kev lag luam loj.	Lawv feem ntau yog siv rau hauv cov khoom siv me me.

Peb Cov Ntawv Pov Thawj thiab Airsoft Tsav

Cov lus nug nquag nug txog Mini DC Tsav

Q: Mini DC lub cev muaj zog yog dab tsi?

A: Lub tshuab hluav taws xob ncaj qha (DC) yog ib hom tshuab hluav taws xob uas hloov hluav taws xob hluav taws xob mus rau hauv lub tshuab hluav taws xob. DC motors siv hluav taws xob hluav taws xob los ntawm cov hluav taws xob ncaj qha, thiab hloov lub zog no rau hauv kev sib hloov tshuab.
DC motors siv magnetic teb uas tshwm sim los ntawm cov hluav taws xob tam sim no generated, uas powers lub zog ntawm ib tug rotor tsau nyob rau hauv lub tso zis ncej. Cov zis torque thiab ceev yog nyob ntawm ob qho tib si hluav taws xob input thiab tsim ntawm lub cev muaj zog.

Q: DC motors ua haujlwm li cas?

A: DC motors suav nrog ob yam tseem ceeb: stator thiab armature. Lub stator yog qhov chaw nres tsheb ntawm lub cev muaj zog, thaum lub armature tig. Nyob rau hauv DC lub cev muaj zog, lub stator muab ib tug rotating magnetic teb uas tsav lub armature tig.

Ib qho yooj yim DC lub cev muaj zog siv cov hlau nplaum nyob ruaj ruaj nyob rau hauv stator, thiab ib lub coil ntawm cov hlau uas muaj tam sim no khiav los ntawm nws los tsim cov electromagnetic teb raws li qhov nruab nrab ntawm lub kauj. Ib los yog ntau lub windings ntawm insulated hlau yog qhwv nyob ib ncig ntawm lub hauv paus ntawm lub cev muaj zog kom mloog zoo rau cov magnetic teb.

Lub windings ntawm insulated hlau yog txuas nrog ib tug commutator (ib tug tig hluav taws xob hloov), uas siv ib tug hluav taws xob tam sim no rau lub windings. Lub commutator tso cai rau txhua lub armature coil kom muaj zog nyob rau hauv lem, tsim ib tug khov kho rotating quab yuam (hu ua torque).

Thaum cov coils raug qhib thiab kaw nyob rau hauv ib ntus, lub rotating magnetic teb yog tsim uas cuam tshuam nrog qhov sib txawv ntawm cov hlau nplaum nyob ruaj ruaj hauv stator los tsim torque, uas ua rau nws tig. Cov ntsiab lus tseem ceeb ntawm kev ua haujlwm ntawm DC motors tso cai rau lawv hloov hluav taws xob hluav taws xob los ntawm cov hluav taws xob ncaj qha mus rau hauv lub zog siv hluav taws xob los ntawm kev sib hloov, uas tuaj yeem siv rau kev txhawb nqa ntawm cov khoom.

Q: Leej twg tsim lub DC lub cev muaj zog?

A: Cov khoom siv hluav taws xob zoo kawg no tau hloov pauv peb lub neej ntau txoj hauv kev, tab sis leej twg tsim lub DC lub cev muaj zog? Raws li nrog rau txhua qhov kev tsim kho tshiab, muaj ntau tus neeg uas muaj lub luag haujlwm los ntawm kev txhim kho cov txheej txheem zoo sib xws.

Nyob rau hauv Teb Chaws Asmeskas, Thomas Davenport yog dav ua kev zoo siab raws li tus inventor ntawm thawj lub cev muaj zog, thiab undoubtedly nws yog thawj zaug patent ib tug siv tau hluav taws xob lub cev muaj zog nyob rau hauv 1837. Davenport, txawm li cas los xij, tsis yog thawj tus neeg tsim lub tshuab hluav taws xob, nrog rau ntau yam. inventors nyob teb chaws Europe twb tau tsim ntau haib versions los ntawm lub sij hawm Davenport tau ua nws patent.

Xyoo 1834, Moritz Jacobi tau nthuav tawm lub cev muaj zog uas muaj peb zaug ntau npaum li qhov Davenport yuav tom qab patent, thaum Sibrandus Stratingh thiab Christopher Becker yog thawj zaug los ua kom pom qhov siv tau rau lub tshuab hluav taws xob, los ntawm kev khiav lub tsheb me me hauv xyoo 1835. .

Thawj lub tswv yim DC lub cev muaj zog tau tsim tawm qee xyoo tom qab xyoo 1886 los ntawm Frank Julian Sprague, nws qhov kev tsim ua rau thawj lub cev muaj zog trolley system hauv xyoo 1887, thiab thawj lub elevator hauv xyoo 1892. Sprague's DC lub cev muaj zog yog qhov kev loj hlob loj heev, ua rau muaj kev txhim kho loj heev. ntau yam kev siv uas yuav hloov lub ntsej muag ntawm kev lag luam thiab kev tsim khoom.

Q: Dab tsi yog kev siv lub tshuab mini?

A: Kev siv me me / mini motors koom nrog ntau yam kev siv xws li tsim qauv mini motor project, CD / DVD players, hard drives, kiv cua, twj, kas fes tshuab, neeg hlau nqus tsev vacuum, hairdryers, mixers, khob cij cutters & spindle drives nyob rau hauv modifiable lossis changeable daim ntawv thov ceev.

Q: Daim ntawv thov twg yog DC lub cev muaj zog siv tau?

A: Cov ntawv thov loj rau DC motors yog: elevators, steel mills, dov mills, locomotives, thiab excavators. Zoo li lwm lub tshuab tig, DC motors tshwm sim los ntawm kev sib cuam tshuam ntawm ob lub hlau nplaum. Kev sib cuam tshuam yog nkag siab zoo tshaj plaws raws li ib qho zoo li cov ncej rov qab (sab qaum teb tus ncej sab qaum teb, sab qab teb tus ncej sab qab teb).

Q: Qhov twg me me DC motors siv nyob rau hauv lub neej txhua hnub?

A: Hauv tsev, DC motors me me yog siv rau hauv cov cuab yeej, cov khoom ua si thiab ntau yam khoom siv hauv tsev. Hauv khw muag khoom, cov kev siv ntawm DC motors muaj xws li conveyors thiab turntables, thaum nyob rau hauv ib qho kev lag luam chaw, loj DC lub cev muaj zog siv kuj muaj xws li braking thiab reversing daim ntaub ntawv.

Q: Kuv puas tuaj yeem txuas mini DC lub cev muaj zog ncaj qha rau roj teeb?

A: Yog, nws yuav zoo siab dua yog tias koj ntsaws rau hauv lub qhov (socket) phab ntsa. Lub qhov (socket) yog qhov tsis zoo yuav AC & tag nrho cov roj teeb yog DC. Yog tias lub cev muaj zog & roj teeb raug ntsuas rau tib qhov voltage & lub roj teeb muaj peev xwm txaus los muab lub cev muaj zog, Tsis muaj teeb meem.

Q: Dab tsi yog qhov voltage ntawm mini DC lub cev muaj zog?

A: Rau mini DC motors, kev khiav hauj lwm voltage yog li ntawm 1.5 txog 100V. Common motors muaj xws li lub mini DC lub cev muaj zog 3V, mini lub cev muaj zog DC 6V, thiab me me 12V DC lub cev muaj zog. Ntawm qhov hluav taws xob siab dua, cov khoom siv hluav taws xob feem ntau ua haujlwm tau zoo dua rau kev khiav lub cev muaj zog.

Q: Yam lub cev muaj zog siv rau hauv cov khoom ua si me me?

A: Toy Small Motor 3-6V DC yog lub cev muaj zog me me feem ntau siv rau hauv cov khoom ua si lossis Robotic tej yaam num rau khiav raws li lub hauv paus lub cev muaj zog nrog 5v mov. Lub cev muaj zog no yog nrov ntawm cov menyuam yaus vim nws tau siv hauv txhua qhov khoom ua si khiav xws li Tsheb, Tsheb, Tsheb nrau av, thiab lwm yam.

Q: Ntev npaum li cas lub DC lub cev muaj zog ua haujlwm tsis tu ncua?

A: Lub sijhawm ua haujlwm tsis tu ncua ntawm DC lub cev muaj zog nyob ntawm ntau yam xws li nws qhov loj me, lub zog ntsuas, tsim, kub, thauj khoom, thiab cua txias. Feem ntau, feem ntau DC motors tuaj yeem khiav tsis tu ncua rau ob peb teev mus rau ntau txhiab teev, nyob ntawm lawv cov kev qhia tshwj xeeb thiab kev ua haujlwm.

Q: Ntev npaum li cas DC lub cev muaj zog?

A: Lub neej ua haujlwm dav dav ntawm DC motors yog li 20, 000 txog 100, 000 teev. Qee cov tuam txhab tsim hluav taws xob zoo yuav muaj cov thev naus laus zis sib xws los ua kom lub cev muaj zog DC kav ntev dua, xws li roj-dawb lubrication, kaw bearings, tiv thaiv overheating, thiab txhim kho lub neej ntawm commutator.

Q: Yuav ua li cas ceev lub me me DC motor spin?

A: DC tswj kev hloov ceev los ntawm qhov sib txawv ntawm qhov hluav taws xob xa mus rau lub cev muaj zog (qhov no txawv ntawm AC lub cev muaj zog tswj uas kho cov kab ntau zaus rau lub cev muaj zog). Hom tsis muaj load lossis synchronous ceev rau AC fractional horsepower lub cev muaj zog yog 1800 lossis 3600 rpm, thiab 1000-5000 rpm rau DC fractional hp motors.

Q: Ntau npaum li cas lub zog DC lub cev muaj zog?

A: Peb muab ntau yam gearheads thiab encoders. Portescap me DC motors tuaj yeem xa cov torque ntau ntawm 0.36 mNm mus txog 160 mNm tsis tu ncua thiab los ntawm 2.5 mNm mus txog 1,487 mNm hauv kev ua haujlwm tsis sib xws.

Q: Kuv puas tuaj yeem khiav 12V DC lub cev muaj zog ntawm 5V?

Q: Yuav ua li cas ceev lub me me DC motor spin?

A: Tej zaum tsis yog. Lub cev muaj zog yuav tsis muaj torque ntau, yog tias muaj. Nyob ntawm qhov loj ntawm lub cev muaj zog qhov kev kos tam sim no yuav nce mus thiab yuav muaj ntau dua li lub charger tuaj yeem muab tau. 5Vdc tsawg dua 1/2 qhov kev cia siab tsav voltage ntawm 12Vdc.

Q: Puas yog DC motors kim?

A: DC motors feem ntau raug nqi ntau dua AC motors vim lawv cov nqi tsim khoom ntau dua. Tsis tas li ntawd, vim tias AC induction motors muaj kev siv dav, kev lag luam ntawm cov nplai ua rau lawv tus nqi qis dua. Qhov no txhais tau hais tias AC motors yog siv rau cov kev lag luam loj feem ntau, qhov DC motors muaj nyob rau hauv cov ntawv me me uas yuav tsum tau tswj kom zoo, xws li cov neeg hlau.

Peb yog cov kws tshaj lij mini DC motor manufacturers hauv Suav teb rau ntau tshaj 15 xyoo, tshwj xeeb hauv kev muab cov khoom lag luam zoo. Peb sov siab txais tos koj rau cov lag luam wholesale bulk mini DC lub cev muaj zog hauv Tshuag ntawm no los ntawm peb lub hoobkas.
