15BY Dc Tsis Txhuam Hniav Qib Thib Ob Lub Vev Tsav Ceev
Fuselage thickness: 11.65mm
Qhov hnyav: Txog 50 g
15BY Dc brushless stepper secondary kuj tsis paub meej ceev tsav
Khoom Piav Qhia
Yam khoom: | CHS-GM29-15BY dc brushless stepper theem nrab kuj tsis paub meej ceev tsav |
Ntev Fuselage: | 52,5 hli |
Fuselage tuab: | 11.65 hli |
Nyhav ： | Txog 50 g |
Tawm axis axis | Hollow heterosexual daim ntawv cog lus axis (saib daim duab rau cov ntsiab lus) |
Daim ntaub ntawv ： | Lub tsev thiab chaw ua haujlwm Automation Tej yam me me platform thiab tshuab kaw lus Cov cuab yeej siv kho mob thiab cuab yeej rau khoom siv Lub kaw qhov ntse thiab ntse teeb pom kev zoo |
Cov duab ntxaws ntxaws
Kev tawm tswv yim stepper lub cev muaj zog tsis
QAUV | CHS-15BY-M3015 | ||
RATED VOLTAGE | 5 V DC (Tsav Tsheb IC: 16219) | TXUJ CI PHEM | 160mA / PHOV |
COIL RESISTANCE | 30 ± 7% ohm / PHASE | NO.OF PHASES | 2 PHAS |
STEP ANGLE | 18 ° / STEP | KEV TXHAWJ XEEM | 2 PHASES KEV NTSEEG |
TSAV TSHEB | BIPOLAR DRIVE | COIL KEV LAG LUAM | 9,5 mH / PHOV |
XAV PAUB NTAU NTXIV | XAV PAUB NTAU NTXIV | ||
RUB-TAWM TORQUE | 4 gf-cm AT 500 pps | KUB TORQUE | 16 gf-cm AT 0 pps |
MAX RESPONSE LOS KAWG | NTAU TSHAJ 1200 pps | MAX STARTING FREQUENCY | TSHAJ NTUJ TSHAJ 900 Phab Ej |
RWB THAIV KAWM | HOOB E RAU COILS | KEV NCAJ NCEES NYOB ZE | 100 V AC RAU IB OB |
KEV KHWV TAU LOS | 50MΩ DC 500V | KEV KAWM TXUJ CI | -0 ～ +55℃ |
Tsim tawm tsis ntawm deceleration lub cev muaj zog
Qauv：CHS-GM29-15BY dctxhuam txhuam stepper ob zaug lub cev muaj zog Voltage: DC 5V | ||||
Tus nqi txo qis | STEP ANGLE | Tsis muaj-nrawm | Tuav torque | Rub-tawm lub zog |
1：5.58×4 | 0.80645 | 134 | ≥0.2 | ≥0.07 |
1：9.68×4 | 0.46488 | 77.5 | ≥0.4 | ≥0.13 |
1：20.50×4 | 0.21951 | 36.6 | ≥0.8 | ≥0.25 |
1：29.12×4 | 0.15453 | 25.8 | ≥1.0 | ≥0.40 |
1：49.99×4 | 0.09002 | 15 | ≥1.8 | ≥0.70 |
1：99.00×4 | 0.04545 | 7.6 | ≥4.0 | ≥1.3 |
1：151.55×4 | 0.02969 | 4.95 | Yuav' t dhau 4.0kg.cm | ≥2.0 |
1：210.59×4 | 0.02137 | 3.56 | ≥2.8 | |
1：297.92×4 | 0.0151 | 2.51 | ≥4.0 | |
1：379.17×4 | 0.01187 | 1.98 | ≥4.5 | |
Khoom& tso saib
Packing& Tus me nyuam
POB:
Txheem export thawv ntim khoom.
TXHUA LUB SIJ HAWM:
3-20 hnub tom qab paub tseeb txog kev txiav txim, kev qhia meej txog hnub xa khoom yuav tsum txiav txim siab raws li
lub caij ua ntau lawm thiab xaj kom muaj nuj nqis.
XAIV:
Yog tias cov ntaub ntawv tshwj xeeb kev lis kev cai tau thov, thov hu rau peb ua ntej kom paub meej.
Cov FAQ
Q: 1.Qhov twg lub cev muaj zog koj tuaj yeem muab tau?
A: Txog tam sim no, Peb feem ntau yog muab lub cev muaj zog me me thiab lub zog ntawm dc deceleration lub cev muaj zog, suav nrog ncaj ncaj deceleration lub cev muaj zog, planetary deceleration tsav, lub cev muaj zog deceleration lub cev muaj zog.Thaum tam sim no, peb lub tuam txhab tsom rau kev tsim ntau yam ntawm cov motors nrog voltage ntawm 1VDC thiab 30VDC thiab lub cev muaj zog ntawm 8 txog 51 hli.
Q: 2. Koj puas tuaj yeem xa kuv daim ntawv qhia nqi?
A: Rau txhua qhov ntawm peb lub zog, lawv tau kho kom haum raws li qhov sib txawv raws li lub neej, suab nrov, voltage, thiab cov nplai thiab lwm yam. Tus nqi kuj sib txawv raws li qhov ntau xyoo. Yog li nws' s yeej nyuaj rau peb los muab cov npe teev nqi. Yog tias koj tuaj yeem qhia koj cov ncauj lus kom ntxaws thiab cov khoom lag luam txhua xyoo, peb' dhau los saib qhov kev pabcuam peb tuaj yeem muab tau.
Q: 3. Dab tsi' s lub sij hawm txhuas rau kev txiav txim ib txwm?
A: Rau cov xaj, lub sijhawm txhuas lub sijhawm yog 3-25 hnub thiab lub sijhawm no tuaj yeem luv dua lossis ntev dua raws li cov qauv sib txawv, sijhawm thiab ntau.
Q: 4. Nws puas tau rau koj kom txhim kho lub zog tshiab yog tias peb tuaj yeem muab cov nqi tsim tawm?
A: Yog lawm. Thov ua siab zoo qhia cov ncauj lus kom ntxaws ntxaws xws li kev ua tau zoo, qhov loj me, cov lus qhia txhua xyoo, tus nqi phiaj.
Q: 5.Hauv koj xa tuaj rau kuv kuaj dawb?
Yog lawm, peb kuj tuaj yeem xa koj cov nqi coj mus kuaj rov qab thaum koj tso qhov kev txiav txim.
Cim npe nrov: 15by dc brushless stepper secondary nce mus nce los ceev lub cev muaj zog, Tuam Tshoj, tuam ntxhab, lub Hoobkas, lag luam, customized, lag luam wholesale, tej, hauv Tshuag
